SPOUT1 variants associated with autosomal-recessive developmental and epileptic encephalopathy

Abstract

Background

Developmental and epileptic encephalopathy (DEE) is a group of neurodevelopmental disorders characterized by early-onset seizures predominantly attributed to genetic causes. Nevertheless, numerous patients remain without identification of a genetic cause.

Methods

We present four unrelated Chinese patients with SPOUT1 compound heterozygous variants, all of whom were diagnosed with DEE. We also investigated functions of SPOUT1 using the spout1 knockout zebrafish model.

Results

The four unrelated DEE patients with SPOUT1 compound heterozygous variants were all males. Their onset age of seizure ranged from 3 months to 6 months (median age 5 months). All patients had epileptic spasms, and were diagnosed with infantile epileptic spasms syndrome (IESS). Three patients had microcephaly during infancy. Brain MRI in three patients showed white matter hypomyelination and bilaterally widened frontotemporal subarachnoid space. At the last follow-up, two patients exhibited drug-resistant epilepsy, one achieved seizure freedom following vigabatrin treatment, and one died at the age of 4 years and 5 months from probable sudden unexpected death in epilepsy. Seven different SPOUT1 variants were identified in the four patients, including six missense variants and one deletion variant. AlphaFold2 prediction indicated that all variants alternated the number or the length of bonds between animo acids in protein SPOUT1. Neurophysiological results from spout1 knockout zebrafish revealed the presence of epileptiform signals in 9 out of 63 spout1 knockout zebrafishes (P = 0.009). Transcriptome sequencing revealed 21 differentially expressed genes between spout1 knockout and control groups, including 13 up-regulated and 8 down-regulated genes. Two axonal transport-related genes, kif3a and ap3d1, were most prominently involved in enriched Gene Ontology (GO) terms.

Conclusions

This study identified SPOUT1 as a novel candidate gene of DEE, which follows the autosomal-recessive inheritance pattern. IESS is the most common epilepsy syndrome. Downregulation of axonal transport-related genes, KIF3A and AP3D1, may play a crucial role in the pathogenesis of DEE.

Background

Developmental and epileptic encephalopathy (DEE) is a group of heterogeneous disorders characterized by early-onset epilepsy, abnormal electroencephalography and developmental delay or regression, predominantly due to genetic factors [1]. DEE causes a high incidence of disability and mortality [2]. With the development of next-generation sequencing technology, 116 DEE-related genes have been discovered and are listed in the Online Mendelian Inheritance in Man database (OMIM). Nevertheless, a significant number of cases remain without definitive genetic explanations.

SPOUT1, also known as CENP32 (Human), C9orf114 (Human) or D2Wsu81e (Mouse), is located at chromosome 9q34.11, which was first reported by Ohta et al. in 2010 [3]. It encodes protein SPOUT domain-containing methyltransferase 1 (SPOUT1), which consists of 376 amino acids. SPOUT1 is highly expressed in the embryonic stage and during childhood, and is widely present in multiple tissues and organs in humans. The function of SPOUT1 is not clear yet. In 2015, Ohta et al. reported that it plays an important role in centrosome integration into a fully functional spindle, and could affect microtubule regrowth and prolong cell cycle [4]. In 2017, Treiber et al. reported that SPOUT1 may act as a methyltransferase to regulate posttranscriptional modification of RNA [5].

However, the associations of SPOUT1 variants with diseases remain largely unknown. In 2014, Fromer et al. identified a heterozygous missense variant p.(Asp37Ala) of SPOUT1 in 1 out of 623 schizophrenia patients [6]. In 2017, Reuter et al. reported two cousins from a consanguineous Israeli family who both carried the homozygous SPOUT1 variant p.(Thr353Met) and were diagnosed with intellectual disability, seizures, microcephaly, short stature, limb hypertonia and bruxism [7].

In this study, we report four unrelated Chinese patients with SPOUT1 compound heterozygous variants who were all diagnosed as DEE, and investigated the pathogenicity of SPOUT1 in zebrafish. These results suggest SPOUT1 as a new candidate pathogenic gene for DEE.

Materials and methods

Patients and clinical assessment

Children were enrolled at the Children’S Medical Center of Peking University First Hospital, Fujian Medical University Union Hospital, and Anhui Children’s Hospital from January 2016 to November 2023. Demographics, clinical manifestations, family history, genetic data, electroencephalography (EEG), neuroimaging, and therapeutic regimes of patients were collected from the clinic. Patients were followed-up at the pediatric neurology clinic or by telephone (Table 1).

Table 1 SPOUT1 compound heterozygous variants in the four patients in our study

This study was approved by the Institutional Review Board of the Ethics Committee of Peking University First Hospital (2005-004). Informed consent was obtained from parents of the children.

Genetic analysis

Variant screening of SPOUT1 (NM_016390, GRCh37/hg19) was performed using whole-exome sequencing or whole-genome sequencing from peripheral blood of probands and their parents. Pathogenicity of variants was interpreted according to the American College of Medical Genetics (ACMG) guidelines [8]. All missense variants were evaluated with the MutationTaster server (http://www.mutationtaster.org/), Polymorphism Phenotyping v2 (http://genetics.bwh.harvard.edu/pph2/), Protein Variation Effect Analyzer (https://www.jcvi.org/research/provean), Sorting Intolerant From Tolerant (http://sift.jcvi.org/), Mendelian Clinically Applicable Pathogenicity (http://bejerano.stanford.edu/mcap/), and Combined Annotation Dependent Depletion v1.7 (https://cadd.gs.washington.edu/download). Potential pathogenic variants were validated in Chigene (Beijing, China). Minor allele frequencies (MAFs) for all these variant sites were obtained from the Genome Aggregation Database, GnomAD (https://gnomad.broadinstitute.org).

Homology modeling of the human SPOUT1

The human SPOUT1 chain used AlphaFold model AF-Q5T280-F1 as the template. And InterPro was used to predict the domain of protein SPOUT1. The protein structures of different variants of SPOUT1 protein were predicted by AlphaFold2 (https://github.com/deepmind/alphafold). The structures have been created by using the PyMOL Molecular Graphics System, Version 2.4.0a0.

CRISPR-mediated knockout of spout1 in Zebrafish

The SPOUT1 ortholog of zebrafish is spout1 (ENSDARG00000019707). To generate spout1 loss-of-function zebrafish, four single-guide RNAs (sgRNAs) were predicted by CHOPCHOP (http://chopchop.cbu.uib.no/) and evaluated by CRISPRater (https://cctop.cos.uni-heidelberg.de/). The sequences of the sgRNAs are as follows: ACAGTGAGCGTGGCTCTGCCTGG (sgRNA1), ACGCTCAGTCTCCAGAGCTGCGG (sgRNA2), ACGCTCAGTCTCCAGAGCTGCGG (sgRNA3), and GAGCTGCGGACGTATCTGGCTGG (sgRNA4). Zebrafish fertilized eggs were collected and injected with ~ 1 nl of CRISPR complexes composed of each sgRNA (90 ng/µL) and Cas9 protein (250 ng/µl). After 24 h, embryos were pooled and Sanger sequenced to verify the mutagenesis efficacy using the TIDE online tool (https://tide.nki.nl/). Two sgRNA sequences with the highest cleavage efficiency, sgRNA2 and sgRNA3, were selected. Each of them was mixed with Cas9 protein, and injected into zebrafish fertilized eggs for CRISPAR knockout of spout1 in zebrafish.

Zebrafish maintenance and breeding

Adult zebrafish were housed in circulating water at 28.5 °C under a 14/10-hour light/dark cycle and were fed twice daily. Zebrafish embryos were obtained through standard mating methods. Larvae were raised in a 28.5 °C incubator with E3 media composed of 0.03% sea salt and 0.00014% methylene blue in reverse osmosis-distilled water. All procedures were conducted following the Guideline for the Care and Use of Animals (2011).

Electrophysiology of zebrafish

Cas9-control and spout1-knockout larvae aged 5–6 days post-fertilization (dpf) were used for electrophysiological recording. They were immobilized in 300 µM pancuronium (Sigma-Aldrich, Missouri, USA) and then embedded in 2% low-melting-point agarose in a recording chamber filled with embryo media. Local field potential (LFP) recording was made from the optic tectum using a glass microelectrode (1-µm diameter, 2–7 MΩ). Electrodes were filled with 2 M NaCl, and electrical activity was recorded using an extracellular amplifier. Data were low-pass filtered at 5 kHz, high-pass filtered at 1 Hz, and digitized at 10 kHz. Recordings were analyzed using the open-source software DClamp.

RNA-Seq and transcriptome analysis

Briefly, RNA was extracted from 5 dpf zebrafish of each group (3 replicates per group). Then, mRNA was extracted by TIANSeq mRNA Capture Kit (TIANGEN, Beijing, China). The transcriptome sequencing libraries was constructed by the TIANSeq Fast RNA Library Kit (Illumina, CA, USA). Clustering of the index-coded samples was performed using the cBot Cluster Generation System with TruSeq PE Cluster Kit v3-cBot-HS (Illumina, CA, USA). The libraries were sequenced using an Illumina Xplus platform and 150-bp paired-end reads were generated.

Clean data were obtained after removing reads containing adapter and low-quality reads with Trimmomatic. Then, the clean data were aligned to the zebrafish reference genome GRCz11 using Hisat2 v2.0.5. Differential expression between the two groups was analyzed using the DESeq2 R package (1.16.1). Differently expressed genes (DEGs) were defined as those with an adjusted P-value less than 0.05 and an absolute value of log₂ fold-change (logFC) greater than 1.

Gene Ontology (GO) enrichment analysis of DEGs was performed with the Database for Annotation, Visualization and Integrated Discovery (DAVID, https://david.ncifcrf.gov/). GO terms with P-value < 0.05 were considered as significantly enriched by DEGs. The volcano map was drawn by R language with ggplot2. The GOCircle and GOChord graphs were plotted by the GOplot package (1.0.2) in R.

Statistics

Statistical analyses were performed using Prism 8 (GraphPad Prism Software, USA). Chi-square test was used for comparison of seizure frequency in zebrafish between groups. P < 0.05 was considered as statistically significant.

Results

Individuals with SPOUT1 compound heterozygous variants display DEE

Genetic testing results

In our study, seven different SPOUT1 variants were identified in four patients, all being compound heterozygous SPOUT1 variants. One variant p.(Arg200Trp) was identified in two unrelated patients. Six variants were missense variants, including p.(Arg200Trp), p.(Cys209Ser), p.(Leu221Pro), p.(Arg349His), p.(Arg352His), and p.(Thr353Met), and the other one was deletion variant, p.(248_249delSer) (Table 1). The MAFs of all seven variants were below 0.001. The six missense variants were predicted to be damaging or probably damaging based on analyses with multiple bioinformatics tools. All seven variants were classified as variants of uncertain significance according to ACMG guidelines (Table 1).

All of the SPOUT1 variants were located within the RNA methyltransferase domain (Fig. 1a). All seven variants were predicted by AlphaFold2 to lead to alterations in the number or the length of bonds between amino acids (Fig. 1b).

Fig. 1

a  SPOUT1 gene, protein regions and variant sites. b Protein structures of different SPOUT1 variants as predicted by AlphaFold

Clinical features

Patients were all males. The four patients with SPOUT1 compound heterozygous variants were from four different families. Three of them had normal family history. Patient 3 had an elder sister who was diagnosed with IESS (Fig. S12-S15). However, detailed clinical data for this patient was not obtained, and follow-up was lost. The age of seizure onset ranged from 3 to 6 months (median age, 5 months). Epileptic spasms were observed in all four patients, with only Patient 1 exhibiting focal seizures during the observation period. All four patients were diagnosed with global developmental delay, and failed to achieve age-appropriate gross motor milestones. Three patients presented with microcephaly during infancy (Table 2).

Table 2 Phenotypes of the four patients with SPOUT1 compound heterozygous variants

Video electroencephalography (VEEG)

All patients exhibited abnormalities on VEEG. Patient 4 demonstrated a background characterized by diffuse slow activity with low voltage. Interictal EEG recordings in three patients revealed atypical hypsarrhythmia, while one patient exhibited hypsarrhythmia (record lost). Multifocal discharges were observed in two patients (Patients 1 and 4). During EEG monitoring, seizures were recorded in three patients (Patients 1, 2 and 4), all of whom experienced epileptic spasms (Table 2; Fig. 2).

Fig. 2

Electroencephalography (EEG) of patients with SPOUT1 variant. Interictal EEG and ictal scalps of Patient 2 (a, b) and Patient 4 (c, d) demonstrating atypical hypsarrhythmia (a, c) and monitored epileptic spasms (b, d)

Neuroimaging

Brain MRI scans revealed white matter hypomyelination and bilaterally widened frontotemporal subarachnoid spaces in three patients (Patients 1, 3 and 4). One patient demonstrated bilateral frontal atrophy over time. Patient 1 exhibited agenesis of the corpus callosum (Table 2; Fig. 3). Patient 2 had normal MRI findings.

Fig. 3

Brain MRI of Patient 1 at age of 5 months (a, b), 1 year and 3 months (c, d) and 2 years and 11 months (e, f). Agenesis of corpus callosum, bilateral frontal atrophy, and white matter hypomyelination were shown

Epileptic syndrome

The four patients were diagnosed with infantile epileptic spasms syndrome (IESS) (Table 2). All had an age of seizure onset before 6 months and exhibited delays in age-appropriate gross motor milestones prior to the onset of seizures. Consequently, they all could be diagnosed with DEE.

Treatment and prognosis

The age of the patients at the final follow-up ranged from 4 years and 5 months to 11 years and 9 months. At the last follow-up, two patients exhibited drug-resistant epilepsy (Patients 1 and 3), and one patient achieved seizure freedom after vigabatrin treatment, and has been off from anti-seizure medication for 8 years (Patient 2). Patient 4 died at age of 4 years and 5 months, due to probable sudden unexpected death in epilepsy (SUDEP).

Knockout of spout1 increases epileptic discharges in zebrafish

To assess the role of SPOUT1 in neurophysiology, we knocked out spout1 in zebrafish and recorded field potentials in the optic tectum of zebrafish at 5–6 days dpf. We detected epileptiform-like signals in only 1 of 62 Cas9-control zebrafish. In contrast, in the spout1-knockout group, 9 out of 63 zebrafish exhibited epileptiform signals, which was significantly different from the Cas9 control group (Chi-square test, P = 0.009; Fig. 4). In summary, our findings suggest that knockout of spout1 in zebrafish increased abnormal EEG epileptic discharges, supporting the association between spout1 gene variants and epilepsy (Fig. S1-S11).

Fig. 4

Representative electrophysiological recordings and statistical analysis of zebrafish between the cas9-control group and spout1-knockout group. **P < 0.01

Knockout of spout1 may lead to the downregulation of axonal transport-related genes KIF3A and AP3D1

To identify the DEGs in spout1-knockout zebrafish, transcriptome sequencing was performed at 5 dpf. RNA-seq identification of DEGs was performed with Hisat2 and DESeq2. A total of 21 genes were differentially expressed, including 13 up-regulated genes and 8 down-regulated genes (Table 3; Fig. 5a). Volcano map showed that potassium ion channel gene kcnj1a.6, gamma-aminobutyric acid (GABA) A receptor gene gabrp, and synapse-related gene sybl1, were down-regulated.

Table 3 Significant differentially expressed genes in spout1-knockout zebrafish

Fig. 5

RNAseq analysis of spout1-knockout zebrafish. a Volcano map of gene expression changes after spout1 knockout. Red dots represent up-regulated genes. Green dots represent downregulated genes. b Significantly enriched GO terms, which were grouped into three categories: molecular function (MF), cellular component (CC) and biological process (BP). c GOCircle plot based on the GOplot analysis of enriched GO term. The inner ring is a barplot where the height of the bar indicates the significance of the GO term (-log10 |P-value|), and color corresponds to the z-score, which indicates increase (red) or decrease (blue). The outer ring displays scatterplots of the expression levels (logFC) of the genes in each term

To further evaluate the biological functions of these DEGs, GO enrichment analysis was performed. Results showed that the DEGs belonged to 15 GO terms, grouped into three categories: molecular function (MF), cellular component (CC) and biological process (BP) (Fig. 5b). The BP category included GO:0008089 anterograde axonal transport, GO:0098930 axonal transport, GO:0008088 axo-dendritic transport, GO:1902578 single-organism localization, GO:0007041 lysosomal transport, GO:0044802 single-organism membrane organization, GO:0006956 complement activation, and GO:0072376 protein activation cascade. The MF category was GO:0004857 enzyme inhibitor activity. In the cellular component, GO:0099568 cytoplasmic region, GO:1904115 axon cytoplasm, GO:0032838 cell projection cytoplasm, GO:0032991 macromolecular complex, GO:0042995 cell projection, and GO:0033267 axon part.

It should be mentioned that GO:1902578, GO:1904115, GO:0008089, GO:0032838, GO:0098930, GO:0008088, and GO:0033267 were negatively regulated as most of their DEGs were down-regulated. On the other hand, GO:0004857, GO:0072376 and GO:0006956 were positively regulated because most of their DEGs were up-regulated (Fig. 5c). Of the DEGs, there were two key genes, kif3a and ap3d1, which were most prominently involved in the enriched GO terms (Fig. 5c). This observation may indicate that genes KIF3A and AP3D1 play an important role in the pathogenesis of SPOUT1 variant related DEE.

Discussion

The concept of DEE was proposed by International League Against Epilepsy (ILAE) in 2017 [1]. Although genetic inheritance is the most common etiology of DEE, a substantial number of patients diagnosed with DEE do not have identifiable pathogenic genes. Recent studies have reported that DEE caused by different genes may exhibit distinct characteristics [9].

IESS is a prevalent clinical epilepsy syndrome of DEE, which has been associated with over 50 genes. Notably, IESS associated with over 90% of these genes demonstrate an autosomal-dominant inheritance pattern. A limited number of genes, including PARS2, BUA5, WWOX, SLC25A22, SZT2, UGDH, and ACTL6B, have been reported to follow an autosomal-recessive inheritance pattern [10,11,12]. In our study, we identified four independent IESS patients carrying compound heterozygous variants of SPOUT1. Based on previous literature, we hypothesize that SPOUT1-related DEE (SPOUT1-DEE) adheres to an autosomal-recessive inheritance pattern [7].

Our four patients with SPOUT1 compound heterozygous variants had similar clinical phenotypes. Their seizure-onset age were below 6 months. The most common seizure type was epileptic spasms, and the most common epilepsy syndrome was IESS. Most of the patients (3/4) had microcephaly. Hypertonia, nystagmus, and protein-energy malnutrition might be the manifestations of SPOUT1-related patients. The neuroimaging features of SPOUT1-DEE included white matter hypomyelination and bilaterally widened frontotemporal subarachnoid spaces in three patients, as well as agenesis of corpus callosum in one patient. One patient exhibited normal brain MRI, potentially due to the younger age. The death of one patient suggests that patients with SPOUT1 variants might have a risk of SUDEP.

A missense variant p.(Arg200Trp) was identified in two independent patients (Patients 1 and 4), who had a seizure onset age of 6 months and 3 months, respectively. Both of them were diagnosed with IESS and microcephaly during infancy. Despite treatment with multiple anti-seizure medications, they continued to experience refractory epilepsy. Their brain MRIs consistently demonstrated white matter hypomyelination and bilateral frontal atrophy. Patient 4 even succumbed to SUDEP at age of 4 years.

In our four patients, we identified seven distinct SPOUT1 variants, predominantly missense variants, with one being deletion variant. MAFs of all these variants were below 0.001. Bioinformatics analyses suggest that all identified variants had the potential to alter the structure and function of SPOUT1 protein. SPOUT1 is known to function as a methyltransferase involved in RNA posttranscriptional modification [5]. Notably, SPOUT1 variants identified in our four patients were located within the RNA methyltransferase domain. Consequently, we hypothesize that the SPOUT1 variants may impair the function of the protein by disrupting RNA methylation processes.

We further studied SPOUT1 function in spout1-knockout zebrafish. Compared to mice that have close physiological and genetic similarity with humans, zebrafish models have advantages in terms of the time cost, high-throughput screening, genetic manipulation, and phenotype display for the research of epilepsy. Recently, a series of investigations have employed zebrafish as an excellent model of epilepsy, to study the mechanisms of epileptogenesis and strategies of epilepsy therapy [13,14,15]. To confirm the relationship between SPOUT1 and epilepsy, we constructed a CRISPR-mediated spout1 knockout zebrafish model. The spout1-knockout zebrafish exhibited significant changes in neural electrophysiology. Following the knockout of spout1, zebrafish exhibited atypical epileptiform discharges, a discharge pattern that was infrequently observed in wild-type zebrafish. This study demonstrated for the first time that the knockout of spout1 could increase epileptic discharges in zebrafish, speculating that it might be involved in the pathogenesis of epilepsy.

Previous studies have shown that a deletion variant of spout1 in chicken DT4 cells did induce a mild growth defect [4]. In our study, we found that knockout of spout1 could increase epileptic discharges in zebrafish. Combined with clinical phenotype spectrum of SPOUT1-DEE patients, we predicted that SPOUT1 variants may potentially result in loss-of-function.

To further investigate the function of SPOUT1, we performed transcriptome sequencing and demonstrated that knockout of spout1 could potentially perturb the development of the nervous system and neural electrophysiology through multiple pathways. A principal effect observed was the alteration of intracellular single-organism localization (GO:1902578), particularly in axonal transport (GO:0098930). This alteration appeared to be mediated by the down-regulated genes kif3a and ap3d1. KIF3A is a microtubule-related anterograde motor in axons [16], and its loss of function leads to abnormal neuronal migration and differentiation, thereby resulting in brain development anomalies in humans [17]. AP3D1 variants have been linked to epilepsy [18]. Knockout of spout1 also induced upregulation of complement activation-related genes c4b and c3a.2. In humans, C4B has been implicated in Alzheimer’s disease [19], indicating that C4B might be involved in brain degeneration. Although some genes involved in signaling pathways such as the potassium ion channel gene kcnj1a.6 and the gamma-aminobutyric acid A receptor gene gabrp, were down-regulated in spout1-knockout zebrafish, their homologues in humans are either not expressed in the brain or are pseudogenes, suggesting a low likelihood of their contribution to brain development disorders and epilepsy. Collectively, our data suggest that spout1 knockout may lead to the downregulation of axonal transport-related genes kif3a and ap3d1, potentially disturbing axonogenesis and neurodevelopment, resulting in DEE. Future studies will be necessary to validate these findings.

Limitation

This study had some limitations. First, the sample size was not large enough. Larger cohorts of SPOUT1-related DEE patients should be employed in future studies. Second, functional analyses for the seven identified SPOUT1 variants remain incomplete. Third, animals differ significantly from humans, thus animal models cannot accurately represent all human characteristics. In future studies, alternative animal models, such as mice, should be used to investigate the function of SPOUT1. Last, there are inherent biological differences between zebrafish and humans. In the further, evidence from human subjects is needed to validate these findings.

Conclusions

SPOUT1-DEE follows an autosomal recessive inheritance pattern. This condition typically manifests in early infancy, and is characterized by IESS. Most of the patients can be diagnosed with microcephaly. Neuroimaging features of SPOUT1-DEE often include white matter hypomyelination and bilaterally widened frontotemporal subarachnoid spaces, which may progress to cerebral atrophy over time. The presence of SPOUT1 variants may also have implications for patient longevity. Spout1 variants might lead to loss of function. Spout1 knockout zebrafish exhibit increased epileptic discharges, accompanied by reduced expression of axonal transport-related genes kif3a and ap3d1. This downregulation potentially disrupts axonogenesis and neurodevelopment, ultimately exacerbating epileptic discharges.
